interCAD® 365

View and share Schematic, Layout, Gerber, ODB++, DWG (DXF) drawings.
interCAD® 365 Basic Price interCAD® 365 Standard Price interCAD® 365 Premium Price

Main function

Simple and Intuitive Schematic and PCB Data Check

BAS
BASIC
STD
STANDARD
PRE
PREMIUM

With the same performance as the ECAD design tool, you can check design data without a dedicated design tool.

Link with OrCAD Capture, PADS Designer, Xpedition Designer are supported, and cross- navigation and selection are available while bringing the Schematic and PCB at the same time.

Supported data formats

  • Supported Schematic Formats
  • Supported PCB Formats
  • CAM/MCAD

Quick search and check net length, trace width, component properties and dimensions

BAS
BASIC
STD
STANDARD
PRE
PREMIUM

Even if you are not a design expert, any user can easily and accurately search ECAD design data and check net length, trace width, component properties, and dimensional information.

  • Easy/convenient layer setting through Quick Menu
  • Search for parts/nets
  • Select parts/nets and check information
  • Measure parts/nets distance

Compare Design Data

BAS
BASIC
STD
STANDARD
PRE
PREMIUM

Easily find differences between current design and previous design with a single click.

The Most Complete PCB Translator

BAS
BASIC
STD
STANDARD
PRE
PREMIUM

PCB design data read through interCAD Editor can be completely converted without errors or cracks.

  • PADS Layout
  • Allegro PCB Designer
  • Board Station Layout
  • Xpedition Layout
  • Altium Designer Layout (will soon update)
  • Zuken Layout (will soon update)

Safe and easy sharing of design data

BAS
BASIC
STD
STANDARD
PRE
PREMIUM

For collaboration, shared/distributed EDA design documents can be encrypted so that unauthorized users cannot read or print them.

  • Password and date restrictions
  • Prevent screen capture and printing
  • Filtering MAC address
  • Hide component/net property values
  • Create EXE file contains viewer and data
  • Create an IXD file that can be opened by interCAD Reader

How to Share ECAD Design Data Using IXD Files

BAS
BASIC
STD
STANDARD
PRE
PREMIUM

If you need to read ECAD design data without ECAD application, you can save the design data as ixd file and open it with interCAD Reader.

RefDes Silkscreen Overlap Checking (DFM)

BAS
BASIC
STD
STANDARD
PRE
PREMIUM

Design errors can be reduced by visually verifying design errors which may occur during PCB manufacturing.

  • Inspect overlapping of Silkscreen, Solder Mask, and Drill Hole
  • Inspect RefDes Text Size
  • RefDes difference order check of parts
  • Inspect RefDes Mirror depends on the arrangement of parts
  • Inspect Reference parts

Products installed by default in interCAD 365

BAS
BASIC
STD
STANDARD
PRE
PREMIUM
interCAD® Basic

Between several types of design tools, ECO (To-Layout), Cross-Probing, Forward Annotation can be supported. No error design can be prepared by verifying causative human errors.
It is software that can innovatively shorten the design speed by providing automotive functions that can not supported by ECAD tools.

interCAD® Wizard

If you input the geometric information of a circuit part, an ECAD library of the part is automatically created. It allows development engineers to create a standard library without having low quality of development and human errors. (will soon update)

interCAD® 365 subscription service

Target SMEs (company’s annual sales of $150M or less) for incumbent employees
License Noded-Lock Type (MAC Address of the PC to be installed)
Contract Replaced by End-User License Agreement (EULA) in the installer
Sale 10% discount for 3 accounts (or more) and over a year
Payment Payment is possible for annually (e-tax invoice can be issued)
Maintenance All technical support (visit or remote) is provided free of charge during the subscription service period
Exclusion If you are a medium-sized company or a large company, please contact support@interxsoft.com.
Try the interCAD® 365 subscription service today!
